TECHNICAL DATA

Manufacturing Standard :- BS 51551 API609/1S 13095
Face to Face (WAFER SHORT) :- BS 51551 API 609 (CATEGORY "A") / iS 13095
End Connection :- WAFER TO SUIT ASME B16.5 150# I DIN 2542 (PN 10)
DIN 2543 (PN 16) I BS10 TABLE 'E'
Inspection & Testing Std :- BS 51551 BS 6755 (Part-1) I API 598/1S 13095

Alternatively device of the disc to shaft    connection can be provided at our option.

Split Body (2pc. body) with replaceable PTFE    seat type valves can be supplied on specific    request of the user/client for severe corrosive    application.

The valve can be supplied with matching    pneumatic or electrically operated actuator    for remote / automated control and    operation.

The design and technical data furnished here    are subject to change due to continuous    product development.

TECHNICAL DATA :-

Manufacturing Std :- API 6D
Face to Face (WAFER SHORT) :- API 6D ( Short Pattern) I ASME B 16.10 (Short Pattern)
End Connection :- WAFER TO SUIT BS10 TABLE 'D' & 'E' I DIN 2542 (PN 10) I DIN 2543 (PN 16) I ASME B16.5, 150#
Inspection and Testing Std :- API 6D I API 598
Rating :- PN 10
Temperature Range :- -20 deg. C to 180 deg. C

Butterfly Valve And Wafer Check Valves - PN 10
