Sizes :
15mm to 25mm
Operating Conditions :
Max. Operating Pressure : 50 Bar
Max. Operating Temperature : 4000C
Min. Operating Pressure : 0.3 Bar
Max. Back Pressure : 80%
End Connections :
Threaded to BSP / BSPT / NPT
Socket Weld to ANSI B 16.11
Installation :
Preferably in a horizontal position
